ComfyUI/README.md

ComfyUI

The most powerful and modular stable diffusion GUI and backend.

This UI will let you design and execute advanced stable diffusion pipelines using a graph/nodes/flowchart based interface. For some workflow examples and see what ComfyUI can do you can check out:

ComfyUI Examples

Installing ComfyUI

Features

• Nodes/graph/flowchart interface to experiment and create complex Stable Diffusion workflows without needing to code anything.
• Fully supports SD1.x, SD2.x, SDXL and Stable Video Diffusion
• Asynchronous Queue system
• Many optimizations: Only re-executes the parts of the workflow that changes between executions.
• Command line option: --lowvram to make it work on GPUs with less than 3GB vram (enabled automatically on GPUs with low vram)
• Works even if you don't have a GPU with: --cpu (slow)
• Can load ckpt, safetensors and diffusers models/checkpoints. Standalone VAEs and CLIP models.
• Embeddings/Textual inversion
• Loras (regular, locon and loha)
• Hypernetworks
• Loading full workflows (with seeds) from generated PNG files.
• Saving/Loading workflows as Json files.
• Nodes interface can be used to create complex workflows like one for Hires fix or much more advanced ones.
• Area Composition
• Inpainting with both regular and inpainting models.
• ControlNet and T2I-Adapter
• Upscale Models (ESRGAN, ESRGAN variants, SwinIR, Swin2SR, etc...)
• unCLIP Models
• GLIGEN
• Model Merging
• LCM models and Loras
• SDXL Turbo
• Latent previews with TAESD
• Starts up very fast.
• Works fully offline: will never download anything.
• Config file to set the search paths for models.

Workflow examples can be found on the Examples page

Getting Started

Installing

You must have Python 3.10, 3.11 or 3.12 installed. On Windows, download the latest Python from their website. You can also directly download 3.11.4 here.

On macOS, install exactly Python 3.11 using brew, which you can download from https://brew.sh, using this command: brew install python@3.11. Do not use 3.9 or older, and do not use 3.12 or newer. Its compatibility with Stable Diffusion in both directions is broken.

1. Create a virtual environment:

   python -m virtualenv venv


2. Activate it on Windows (PowerShell):

Set-ExecutionPolicy Unrestricted -Scope Process
& .\venv\Scripts\activate.ps1

Linux and macOS

source ./venv/bin/activate

3. Then, run the following command to install comfyui into your current environment. This will correctly select the version of pytorch that matches the GPU on your machine (NVIDIA or CPU on Windows, NVIDIA AMD or CPU on Linux):

   pip install git+https://github.com/hiddenswitch/ComfyUI.git


   Advanced: If you are running in Google Collab or another environment which has already installed torch for you, disable build isolation, and the package will recognize your currently installed torch.

   # You will need wheel, which isn't included in Python 3.11 or later
   pip install wheel
   pip install --no-build-isolation git+https://github.com/hiddenswitch/ComfyUI.git


4. To run the web server:

   comfyui


   Create the directories you can fill with checkpoints:

   comfyui --create-directories


   Your current working directory is wherever you started running comfyui. You don't need to clone this repository, observe it is omitted from the instructions. You can cd into a different directory containing models/, or if the models are located somehwere else, like C:/some directory/models, do:

   comfyui --cwd="C:/some directory/"


   You can see all the command line options with hints using comfyui --help.

Manual Install (Windows, Linux, macOS) For Development

1. Clone this repo:

   git clone https://github.com/comfyanonymous/ComfyUI.git
   cd ComfyUI


2. Put your Stable Diffusion checkpoints (the huge ckpt/safetensors files) into the models/checkpoints folder. You can download SD v1.5 using the following command:

   curl -L https://huggingface.co/runwayml/stable-diffusion-v1-5/resolve/main/v1-5-pruned-emaonly.ckpt -o ./models/checkpoints/v1-5-pruned-emaonly.ckpt


3. Create a virtual environment:

   1. Create an environment:

      python -m virtualenv venv


   2. Activate it:

      Windows (PowerShell):

      Set-ExecutionPolicy Unrestricted -Scope Process
      & .\venv\Scripts\activate.ps1


      Linux and macOS

      source ./venv/bin/activate


4. Then, run the following command to install comfyui into your current environment. This will correctly select the version of pytorch that matches the GPU on your machine (NVIDIA or CPU on Windows, NVIDIA AMD or CPU on Linux):

   pip install -e .[dev]


5. To run the web server:

   comfyui


   To generate python OpenAPI models:

   comfyui-openapi-gen


   To run tests:

   pytest tests/inference
   (cd tests-ui && npm ci && npm run test:generate && npm test)


   You can use comfyui as an API. Visit the OpenAPI specification. This file can be used to generate typed clients for your preferred language.

6. To create the standalone binary:

   python -m PyInstaller --onefile --noupx -n ComfyUI --add-data="comfy/;comfy/" --paths $(pwd) --paths comfy/cmd main.py


Because the package is installed "editably" with pip install -e ., any changes you make to the repository will affect the next launch of comfy. In IDEA based editors like PyCharm and IntelliJ, the Relodium plugin supports modifying your custom nodes or similar code while the server is running.

Intel, DirectML and AMD Experimental Support

#### [Intel Arc](https://github.com/comfyanonymous/ComfyUI/discussions/476)

DirectML (AMD Cards on Windows)

Follow the manual installation steps. Then:

pip uninstall torch torchvision torchaudio
pip install torch torchvision torchaudio
pip install torch-directml

Then, launch ComfyUI with comfyui --directml.

For AMD cards not officially supported by ROCm

Try running it with this command if you have issues:

For 6700, 6600 and maybe other RDNA2 or older: HSA_OVERRIDE_GFX_VERSION=10.3.0 comfyui

For AMD 7600 and maybe other RDNA3 cards: HSA_OVERRIDE_GFX_VERSION=11.0.0 comfyui

`

Custom Nodes

Custom Nodes can be added to ComfyUI by copying and pasting Python files into your ./custom_nodes directory.

Authoring Custom Nodes

Create a requirements.txt:

comfyui

Observe comfyui is now a requirement for using your custom nodes. This will ensure you will be able to access comfyui as a library. For example, your code will now be able to import the folder paths using from comfyui.cmd import folder_paths. Because you will be using my fork, use this:

comfyui @ git+https://github.com/hiddenswitch/ComfyUI.git

Additionally, create a pyproject.toml:

[build-system]
requires = ["setuptools", "wheel", "pip"]
build-backend = "setuptools.build_meta"

This ensures you will be compatible with later versions of Python.

Finally, move your nodes to a directory with an empty __init__.py, i.e., a package. You should have a file structure like this:

# the root of your git repository
/.git
/pyproject.toml
/requirements.txt
/mypackage_custom_nodes/__init__.py
/mypackage_custom_nodes/some_nodes.py

Finally, create a setup.py at the root of your custom nodes package / repository. Here is an example:

setup.py

from setuptools import setup, find_packages
import os.path

setup(
    name="mypackage",
    version="0.0.1",
    packages=find_packages(),
    install_requires=open(os.path.join(os.path.dirname(__file__), "requirements.txt")).readlines(),
    author='',
    author_email='',
    description='',
    entry_points={
        'comfyui.custom_nodes': [
            'mypackage = mypackage_custom_nodes',
        ],
    },
)

All .py files located in the package specified by the entrypoint with your package's name will be scanned for node class mappings declared like this:

NODE_CLASS_MAPPINGS = {
    "BinaryPreprocessor": Binary_Preprocessor
}
NODE_DISPLAY_NAME_MAPPINGS = {
    "BinaryPreprocessor": "Binary Lines"
}

These packages will be scanned recursively.

Troubleshooting

I see a message like RuntimeError: '"upsample_bilinear2d_channels_last" not implemented for 'Half''

You must use Python 3.11 on macOS devices, and update to at least Ventura.

I see a message like Error while deserializing header: HeaderTooLarge

Download your model file again.

Using the Editor

Notes

Only parts of the graph that have an output with all the correct inputs will be executed.

Only parts of the graph that change from each execution to the next will be executed, if you submit the same graph twice only the first will be executed. If you change the last part of the graph only the part you changed and the part that depends on it will be executed.

Dragging a generated png on the webpage or loading one will give you the full workflow including seeds that were used to create it.

You can use () to change emphasis of a word or phrase like: (good code:1.2) or (bad code:0.8). The default emphasis for () is 1.1. To use () characters in your actual prompt escape them like \( or \).

You can use {day|night}, for wildcard/dynamic prompts. With this syntax "{wild|card|test}" will be randomly replaced by either "wild", "card" or "test" by the frontend every time you queue the prompt. To use {} characters in your actual prompt escape them like: \{ or \}.

Dynamic prompts also support C-style comments, like // comment or /* comment */.

To use a textual inversion concepts/embeddings in a text prompt put them in the models/embeddings directory and use them in the CLIPTextEncode node like this (you can omit the .pt extension):

embedding:embedding_filename.pt

How to increase generation speed?

Make sure you use the regular loaders/Load Checkpoint node to load checkpoints. It will auto pick the right settings depending on your GPU.

You can set this command line setting to disable the upcasting to fp32 in some cross attention operations which will increase your speed. Note that this will very likely give you black images on SD2.x models. If you use xformers or pytorch attention this option does not do anything.

--dont-upcast-attention

How to show high-quality previews?

Use --preview-method auto to enable previews.

The default installation includes a fast latent preview method that's low-resolution. To enable higher-quality previews with TAESD, download the taesd_decoder.pth (for SD1.x and SD2.x) and taesdxl_decoder.pth (for SDXL) models and place them in the models/vae_approx folder. Once they're installed, restart ComfyUI to enable high-quality previews.

Keyboard Shortcuts

Keybind	Explanation
Ctrl + Enter	Queue up current graph for generation
Ctrl + Shift + Enter	Queue up current graph as first for generation
Ctrl + Z/Ctrl + Y	Undo/Redo
Ctrl + S	Save workflow
Ctrl + O	Load workflow
Ctrl + A	Select all nodes
Alt + C	Collapse/uncollapse selected nodes
Ctrl + M	Mute/unmute selected nodes
Ctrl + B	Bypass selected nodes (acts like the node was removed from the graph and the wires reconnected through)
Delete/Backspace	Delete selected nodes
Ctrl + Delete/Backspace	Delete the current graph
Space	Move the canvas around when held and moving the cursor
Ctrl/Shift + Click	Add clicked node to selection
Ctrl + C/Ctrl + V	Copy and paste selected nodes (without maintaining connections to outputs of unselected nodes)
Ctrl + C/Ctrl + Shift + V	Copy and paste selected nodes (maintaining connections from outputs of unselected nodes to inputs of pasted nodes)
Shift + Drag	Move multiple selected nodes at the same time
Ctrl + D	Load default graph
Q	Toggle visibility of the queue
H	Toggle visibility of history
R	Refresh graph
Double-Click LMB	Open node quick search palette

Ctrl can also be replaced with Cmd instead for macOS users

Distributed, Multi-Process and Multi-GPU Comfy

This package supports multi-processing across machines using RabbitMQ. This means you can launch multiple ComfyUI backend workers and queue prompts against them from multiple frontends.

Getting Started

ComfyUI has two roles: worker and frontend. An unlimited number of workers can consume and execute workflows (prompts) in parallel; and an unlimited number of frontends can submit jobs. All of the frontends' API calls will operate transparently against your collection of workers, including progress notifications from the websocket.

To share work among multiple workers and frontends, ComfyUI uses RabbitMQ or any AMQP-compatible message queue like SQS or Kafka.

Example with RabbitMQ and File Share

On a machine in your local network, install Docker and run RabbitMQ:

docker run -it --rm --name rabbitmq -p 5672:5672 rabbitmq:latest

Find the machine's main LAN IP address:

Windows (PowerShell):

Get-NetIPConfiguration | Where-Object { $_.InterfaceAlias -like '*Ethernet*' -and $_.IPv4DefaultGateway -ne $null } | ForEach-Object { $_.IPv4Address.IPAddress }

Linux

ip -4 addr show $(ip route show default | awk '/default/ {print $5}') | grep -oP 'inet \K[\d.]+'

macOS

ifconfig $(route get default | grep interface | awk '{print $2}') | awk '/inet / {print $2; exit}'

On my machine, this prints 10.1.0.100, which is a local LAN IP that other hosts on my network can reach.

On this machine, you can also set up a file share for models, outputs and inputs.

Once you have installed this Python package following the installation steps, you can start a worker using:

Starting a Worker:

# you must replace the IP address with the one you printed above
comfyui-worker --distributed-queue-connection-uri="amqp://guest@guest10.1.0.100"

All the normal command line arguments are supported. This means you can use --cwd to point to a file share containing the models/ directory:

comfyui-worker --cwd //10.1.0.100/shared/workspace --distributed-queue-connection-uri="amqp://guest@guest10.1.0.100"

Starting a Frontend:

comfyui --listen --distributed-queue-connection-uri="amqp://guest@guest10.1.0.100" --distributed-queue-frontend

However, the frontend will not be able to find the output images or models to show the client by default. You must specify a place where the frontend can find the same outputs and models that are available to the backends:

comfyui --cwd //10.1.0.100/shared/workspace --listen --distributed-queue-connection-uri="amqp://guest@guest10.1.0.100" --distributed-queue-frontend

You can carefully mount network directories into outputs/ and inputs/ such that they are shared among workers and frontends; you can store the models/ on each machine, or serve them over a file share too.

Operating

The frontend expects to find the referenced output images in its --output-directory or in the default outputs/ under --cwd (aka the "workspace").

This means that workers and frontends do not have to have the same argument to --cwd. The paths that are passed to the frontend, such as the inputs/ and outputs/ directories, must have the same contents as the paths passed as those directories to the workers.

Since reading models like large checkpoints over the network can be slow, you can use --extra-model-paths-config to specify additional model paths. Or, you can use --cwd some/path, where some/path is a local directory, and, and mount some/path/outputs to a network directory.

Community

Chat on Matrix: #comfyui_space:matrix.org, an alternative to Discord.
